Panasonic HIT Power N330SA16 330W Mono BLK/WHT Solar Panel

$359.00

Panasonic HIT Solar Panels

Module Technology: HIT
Dimensions: 62.6 × 41.5 × 1.4 in
Weight: 40.81 lb
Cells Per Module: 60
Module Frame Material: Black Anodized
Module Frame Thickness: 35mm
Module Backsheet Material: White
Module Connector: MC4
Module Output Cables: PV Wire

Module Watts STC: 330 Watts
Module Watts PTC: 311.30 Watts
Max Power Voltage (Vmpp): 58.00 Volts
Max Power Current (Impp): 5.70 Amps
Open Circuit Voltage (Voc): 69.70 Volts
Short Circuit Current (Isc): 6.07 Amps
Max System Voltage: 600.00 Volts
Series Fuse Rating: 15 Amps
Module Efficiency: 19.70%

SKU: VBHN330SA16 Category:

Additional information

Weight40.81 lbs
Dimensions62.6 × 41.5 × 1.4 in
